High Quality Construction material U steel channel
- Price
- US $550
- Model
- 5#-40#
- MOQ
- 20 metric ton
Item specifics
- Product name
- U Channel
- Material
- Q195-Q345/SS400/ss335/ST37/S235JR/S275JR
- Color
- Metal Color
- shipment
- by break bulk or by container
- Technique
- hot rolled
- Length
- 6m-12m
- Standard
- JIS, DIN, EN, GB, ASTM, ASNZ
- Finish
- Black or Galvanized
- type
- steel U profile
- Model Number
- 5#-40#
Review
Description
High Quality Construction material U steel channel
U channel steel size (JIS standard)
| size | Web Thickness (mm) | Leg Thickness (mm) | Theoretical weight (kg/m) |
| 75*40 | 3.8 | 7 | 5.3 |
| 4 | 7 | 5.6 | |
| 4.5 | 7 | 5.85 | |
| 5 | 7 | 6.92 | |
| 100*50 | 3.8 | 6 | 7.3 |
| 4.2 | 6 | 8.03 | |
| 4.5 | 7.5 | 8.97 | |
| 5 | 7.5 | 9.36 | |
| 125*65 | 5.2 | 6.8 | 11.66 |
| 5.3 | 6.8 | 12.17 | |
| 5.5 | 8 | 12.91 | |
| 6 | 8 | 13.4 | |
| 150*75 | 5.5 | 7.3 | 14.66 |
| 5.7 | 10 | 16.71 | |
| 6 | 10 | 17.9 | |
| 6.5 | 10 | 18.6 | |
| 9 | 12.5 | 24 | |
| 200*80 | 7.5 | 11 | 24.6 |
| Products | U Channel Steel |
| Grade | Q235B,Q345B |
| Type | GB standard(10#-40#,100*48mm--400*102mm) JIS standard(50*25mm--250*90mm) |
| Length | 6m, 12m,Large quantity can be customized |
| Technique | Hot rolled |
| Application | Mainly used for building structure, vehicle manufacturing and other industrial structure, channel steel is often used with i beam |
| Payment Terms | L/C , T/T or Western Union |
